Safety Arrangements

Lazer Safe - Performance Without Compromise

The LZS Series and IRIS Series Safety laser protection provide superior optical protection while maintaining the highest level of productivity and performance for CNC press brake.

Optical Safety System - Advanced

ACCURL® CNC press brake use OEM EMBEDDED LAZERSAFE offers a highly effective solution for both operator safety and machine productivity. Designed for use with Lazer Safe’s PCSS A Service, the Lazersafe is category 4 compliant and meets the world’s most demanding international safety standards(CE Certified Category 4 Safety Controller with integrated).

Optional:

Optical Safety System Advanced

Advantage:

Automatic Tool Alignment: ​

The systems with a camera receiver feature automatic tool alignment that eliminates the need for precise manual adjustment, and this process can also be fully automated in the CNC via SmartLink, eliminating the need for the operator to press the TOOL ALIGN button.

Safety Arrangements - 1
Safety Arrangements - 2

Certification And Standards Compliance:

The OEM Embedded Systems LZS Series and IRIS Series hardware and software is CE Certified and compliant with all international press brake safety standards including EN12622, ANSI B11.3-2012, CSA Z142-10 and NR12.
RapidBend

Rapid Bend

SmartLink

Smart Link

FlexSpeed

Flex Speed

AutoSense

Auto Sense

BendShield

Bend Shield

Bendvision

Bend Vision

Press Brake Control Safety System - Advanced

The PCSS-A is a programmable safety controller designed to improve the performance and safety of press brakes. It provides flexibility for the press brake manufacturer and simplifies the design process by combining all related control, safety and monitoring functions into a single system and eliminates the need for complex integration of third party components and software. PCSS-A provides an optimum balance of functionality and performance with reduced build cost.

Press Brake Control Safety System - Advanced Diagram
This provides an efficient and cost effective platform with fewer components, reduced wiring, simplified interface and CE Certified hardware and software to minimise engineering and build time.

Specifications

PCSS-A0 PCSS-A0 PLUS PCSS-A1 PCSS-A2
Technology
SmartLink
FlexSpeedPlus
AutoSensePlusUltimateUltimate Ultimate
Specifications
Safety inputs 12121616
Safety outputs 4466
Standard inputs 24242828
Standard outputs 661010
Linear encoder I/O 1, Y1 or Y2 2, both Y1 and Y2 2, both Y1 and Y2 2, both Y1 and Y2
Minimum encoder resolution 0.1 micron 0.1 micron 0.1 micron 0.1 micron
Speed capacity of the encoder counters >300mm per second > 300mm per second > 300mm per second > 300mm per second
Response time (hardware interrupts) <1ms <1ms <1ms <1ms
SD Card (back-up, data logging and high-speed software transfer) ---
CAN Open ---
Ethernet--
Ether CAT---OPTIONAL
Dimensions229mm x 189mm x 45mm229mm x 189mm x 45mm229mm x 189mm x 45mm229mm x 189mm x 57mm
Expansion Options
Tandem Adaptor --
SmartLink Brackets --
Wireless Foot Pedal --
Optics Compatibility
LZS-1
LZS-2
LZS-XL --
IRIS / IRIS Plus --
Third party light curtain support
Dual guarding support

LZS-1 LZS-2 LZS-XL IRISIRIS PLUS
Optical protection functions
Optical imaging functions ---
Laser transmitter CLASS 1CLASS 1 CLASS 1 CLASS 1 CLASS 1
Receiver type Multi-sensor photocell Multi-sensor photocell CameraCamera with integrated Intel® image processor Camera with integrated high-speed Intel® image processor
Maximum recommended optical range 8 metres 8 metres 15 metres 8 metres 4.5 metres
Minimum object detection resolution 4mm4mm9mm2mm2mm
Connector type M12 8 pin M12 8 pin M12 12 pin M12 12 pin M12 12 pin
Tool compatibility V tools and non-standard tools V tools and non-standard tools V tools and non-standard tools V tools and non-standard tools V tools and non-standard tools
Integrated status LEDs
Special Functions
Automatic tool alignment ---
Automatic alignment confirmation ----
Special tools mode ---
Soft stop mode ---
Fast flattening mode ---
Automatic Cycle Start (ACS) ---
Bend Speed Management (BSM) ---
Adaptive Environment Sensing (AES) --
Technology
RapidBend----
RapidBend Ultimate ---
BendShield---
BendVision----
Performance // Minimum speed change point
Flat sheet bending 8mm4mm3mm / 10mm 0mm0mm
Box bending 8mm4mm3mm / 10mm 0mm0mm
PCSS-A Series Compatibility
PCSS-A0 / PCSS-A0 Plus ---
PCSS-A1 / PCSS-A2
PCSS-A Tandem Adaptor ----
Mounting Bracket Compatibility
Economy Brackets ---
Standard Brackets
SmartLink Brackets ---

IRISIRIS PLUS
Optical protection functions
Optical imaging functions
Maximum recommended optical range 8 metres 4.5 metres
Optical sensor
CameraDigital Image Sensor Digital Image Sensor
Frame rate / frequency 17ms / 59Hz Selectable 5ms / 200Hz or 10ms / 100Hz
Data resolution (sensor) -0.01 degrees
Measurement technology
TypeIntegrated
Intel® image processor
Integrated high-speed Intel® image processor
Memory depth -Records up to 10 seconds (2000 images) of bend data per cycle
Measurement accuracy -Up to +/- 0.25 degrees
Measurement rate synchronised with frame rate -Selectable 5ms / 200Hz or 10ms / 100Hz
Imaging technology
Bend Speed Management
BendVision -

ECONOMYSTANDARDSMARTLINK
Specifications
Vertical bracket length 700mm520mm / 700mm / 1000mm 700mm
Vertical adjustment range 488mm350mm / 530mm / 830mm 500mm
Horizontal adjustment range 40mm40mm40mm
Maximum recommended machine length 4 metres 15 metres 6 metres
Main Features
Precision linear bearings and rails -
Free sliding operation -
Automatic motorised drive system --
Maximum speed of the motorised drive system NANA20mm/s
Adjustable locking handle NA
Tool change lock -ManualAutomatic
Optics Compatibility
LZS-1 -
LZS-2 -
LZS-XL --
IRIS / IRIS Plus -
