Description
ACCURL IPG 6000W Fiber Laser Cutting Machine Price with Fiber Laser Cutting Machine Manufacturers
Incredibly fast and flexible, the ACCURL Genius 6kw fiber laser cutter is ideal for ultra-high speed cutting of thin sheet materials.the Genius has the ability to cut a wide range of ferrous and non-ferrous metals while maintaining low cost operation.
- User friendly FAGOR 8060 CNC control unit.
- Unique features:
- Maximum simultaneous positioning speed: 160m/min.
- Acceleration speed: 25 m/ s2 (2.5G).
- Precision: ± 0.05 mm.
- Energy efficiency: greatly reduced power consumption.
- IPG YLS-6000w Resonator
- Advanced PRECITEC cutting head (with air cross blast).
- Fully enclosed and cabined to ensure maximum operator protection.
- Effective high to low pressure gas exchange system.
- Automatic time and unit cost calculation function.
- Network connection from external.
- Smoke extraction (included in series models).
- Collection of work pieces and trimmings.
- Dual proportional valve control system for different gas pressures and special system for high pressure cutting.
Standard Equipment:
- FAGOR 8060 CNC Controller
- IPG YLS-6000W Ytterbium Laser Resonator
- Automatic Double Pallet Changer(Shuttle Table)
- Precision Rack & Pinion Drive System (Made in Germany)
- Radan or Lantek CAD/CAM system
- Light source
- Chiller
- 3 lower protective lenses
- 3 Ceramic Nozzle Adapters
- Auto-calibrated nozzle system
- Lens with 5.9” Focus Length
- Smart Slag Collection System/ Chip Conveyor
- Fiber Beam Transmission System (Fiber Cable)
- Operates with both N2 and O2 (cutting) gases
- Home Position Alignment System
- Auxiliary Gas Selector
- Auto Reflection Warning
- Working Lights
- 5 Nozzles each of the Following: (1.0mm, 1.2mm,1.5mm, 2.0mm , 2.5mm , 3.0mm)
Technical Specifications
| Model: | ECO-FIBER 3015 / 6KW |
| CNC Control Unit | FAGOR 8060 CNC System |
| X axis (Rack & Pinion) | 3000 mm |
| Y axis (Rack & Pinion) | 1500 mm |
| Z axis (Ball Screw) | 100 mm |
| Maximum cutting capacity | Mild steel: 32 mm |
| Maximum cutting capacity | Stainless Steel: 16 mm |
| Maximum cutting capacity | Aluminum: 16 mm |
| Work piece dimensions | 1525 x 3050 mm |
| Rapid traverse (X and Y axis) | 105 m/min |
| Acceleration | 2.5G (25m/s2) |
| Vector speed | 148 m/min |
| Absolute positioning accuracy | ± 0.08 mm |
| Repeatability (X and Y axis) | ± 0.03 mm |
| Max. load capacity | 2450 kg |
| High Performance CNC System | FAGOR 8060 from Spain Brand |
| Laser power | IPG YLS-6 kW from Germany |
| High PerformanceServo motor/drive | FAGOR from Spain Brand |
| Laser Cutting Head | PRECITEC from Germany |
| Motoreducer | STOBER from Germany |
